    Cast Iron Carton Corrugated Board Slotting Printing And Cutting Machine

    Ask Lasest Price
    Brand Name : XINTIAN, SINCERITY
    Certification : CE,ISO9001
    Price : $4500
    Delivery Time : 30-60days
    Payment Terms : T/T or L/C
    Supply Ability : 50 SET/MONTH
    • Product Details
    • Company Profile

    Cast Iron Carton Corrugated Board Slotting Printing And Cutting Machine

    Cast Iron Carton Corrugated Board Slotting Printing And Cutting Machine


    Specifications

    1.double reduction gearing.
    2.Cast iron Structure.
    3.Belt and Wheel gear transmit.
    4.Fast Change slot size.
    5.Operating easy


    General function:

    It is mainly for Corrugated carton board’s slotting and cutting,According to adjust the knive' broadwise,you
    can get the right slotting size. Operating easily,Working durable.Fast Changing size,easy repairing,maintain
    etc.


    If you are interested in purchasing this kind of machine,
    Below 4 points are necessary for your reference:

    1, Including structure,transmit,plate,motor.
    2, Main Drive:double reduction gearing,First is V-belt,
    Second is wheel gear ,The Drive was protected beneath the Cover.
    3, Structure was made by Cast iron,Durable.
    4, The machine was mainly depend on the Belt and Wheel gear put the crank axle into motion,
    finish slotting.


    Main Specifications:

    Model

    CN301-2000

    CN301-2500

    CN301-3000

    CN301-3500

    Width of carton board(mm)

    2000

    2500

    3000

    3500

    Size of slotting(W×D)(mm)

    7.5×350

    7.5×350

    7.5×550

    7.5×630

    Size of corner cutting(W×D)(mm)

    60×350

    60×350

    80×580

    80×650

    Cutting speed(pcs/min)

    45

    45

    45

    45

    Power(kw)

    1.5

    1.5

    2.2

    3

    Weigth(kg)

    1000

    1200

    2000

    3200

    Dimension(L×W×H)(mm)

    2600×1170×1500

    3100×1170×1500

    3600×1600×1800

    4100×1600×1800

    Quality Cast Iron Carton Corrugated Board Slotting Printing And Cutting Machine for sale
